Steel Beam

This picture shows a steel beam. Steel beams are used in reinforced concrete and provide more strength to the structure.

Steel Beam

Electricity Conduits

Electricity conduits which are lay down after tying the roof iron bars with bending wires. These conduits are layed prior to concrete pouring and are fixed properly and checked as once we pour concrete, we can not change them afterwards

Concrete being poured

Concrete Pouring

Concrete being poured on the iron mesh after being lifted in a trolley. This method of pouring concrete is very fast as compared to old method of using a carrying bucket.

Concrete being poured

Concrete Mixer

A concrete mixer working at a residential area. This mixer saves a lot of time in manually mixing and lifting concrete to the roof. With the help of this machine, time spent as well as efforts are considerably reduced.

Concrete Mixer

Slab Shuttering

Following picture shows the shuttering used for slabs.

This kind of steel shuttering is very useful as it reduces the plastering works. More over wooden logs are hard to remove and also cause breaking of edges. The steel shuttering when used with proper oiling is much easier to remove and also offers excellent finishing. All large projects use this kind of shuttering, only small house constructions are still using wooden planks and that too only in developing countries

slab shuttering
